CUSTOM SIZED GATES IN ALBERTA SINCE 1987

The selection range at Duraguard Fence Ltd. includes everything from a simple galvanized residential single swing to an automatic ornamental wrought iron gate. We don’t want our customers to be stuck with ill-fitting stock sized gates. At Duraguard, we customize extremely large gates suitable for a commercial, industrial, or a residential yard. If you’re looking for a custom gate contractor in Alberta to build you a galvanized gate for your property or site, we would be happy to customize one (or multiple) such gates according to your specifications. Simply get in touch with us with your requirements, and we will give you a quote.

Gate Frame Hinges
press to zoom
1/1

Gate Frame Hinges - Regular - Pressed Steel - Galvanized

Bolts Sold Separately


Description | Per Sack | Weight Ea.

1 3/8" x 5/8" | 50 | 0.31

1 5/8" x 5/8" | 50 | 0.52

1 7/8" x 5/8" | 50 | 0.54

Use 3/8" x 2" or 3/8" x 2 1/2" Carriage Bolt

Gate Post Hinges
press to zoom
1/1

Gate Post Hinges - Regular

Bolts Sold Separately


Description | Per Sack | Weight Ea.

1 5/8" x 5/8" | 50 | 0.44

Use 3/8" x 2" Carriage Bolt


1 7/8" x 5/8" | 50 | 0.51

Use 3/8" x 2 1/2" Carriage Bolt


2 3/8" x 5/8" | 50 | 0.56

Use 3/8" x 3" Carriage Bolt


2 7/8" x 5/8" | 50 | 1.11

Use 3/8" x 3 1/2" Carriage Bolt

Gate Post Collar
press to zoom
1/1

Gate Post Collar - Industrial

Interlocking


Description | Per Sack | Weight Ea.

2 3/8" x 3/4" | 40 | 0.80

2 7/8" x 3/4" | 35 | 1.00

3 1/2" x 3/4" | 30 | 1.25

4 1/2" x 3/4" | 20 | 1.50

Gate Post Collar
press to zoom
1/1

Gate Post Collar - Industrial

c/w 5/8" x 2 1/2" Back Bolt


Description | Per Sack | Weight Ea.

2 7/8" x 3/4" | 35 | 1.00

3 1/2" x 3/4" | 30 | 1.25

4 1/2" x 3/4" | 20 | 1.50

6 5/8" x 1" | 5 | 16.00

Hanger Bolt Hinges
press to zoom
1/1

Hanger Bolt Hinges

c/w 2 Nuts


Description | Per Sack | Weight Ea.

5/8" x 6" | 50 | 0.74

5/8" x 10" | 50 | 1.07

3/4" x 6" | 50 | 1.07

3/4" x 12" | 50 | 1.23

1" x 9" | 1 | 3.50

Lag Screw Hinges
press to zoom
1/1

Lag Screw Hinges

Bolts included | Sizes: frame size x post size


Description | Per Sack | Weight Ea.

5/8" x 4 1/2" | 300 | 0.52

5/8" x 6" | 250 | 0.62

Gate Frame Collar Hinge
press to zoom
1/1

Gate Frame Collar Hinge

Description | Per Sack | Weight Ea.

1 3/8" x 3/4" | 25 | 0.89

1 5/8" x 3/4" | 25 | 0.90

Fork Latch Assembly
press to zoom
1/1

Fork Latch Assembly - Regular

Bolts included | Sizes: frame size x post size


Description | Per Sack | Weight Ea.

1 3/8" x 1 7/8" | 25 | 0.88

1 3/8" x 2 3/8" | 25 | 0.86

Fork Latch Assembly
press to zoom
1/1

Fork Latch Assembly - Heavy Duty

Bolts included


Sizes: frame size x post size


Description | Per Sack | Weight Ea.

1 3/8" x 1 7/8" | 25 | 0.90

1 3/8" x 2 3/8" | 25 | 1.02

1 3/8" x 2 7/8" | 25 | 1.08

1 5/8" x 1 7/8" | 25 | 1.01

1 5/8" x 2 3/8" | 25 | 1.00

1 5/8" x 2 7/8" | 25 | 1.08

1 5/8" x 3 1/2" | 25 | 1.20

Fork Latch Assembly
press to zoom
1/1

Fork Latch Assembly - Heavy Duty

Bolts included


Sizes: frame size x post size


Description | Per Sack | Weight Ea.

1 3/8" x 1 7/8" | 25 | 1.40

1 3/8" x 2 3/8" | 25 | 1.45

1 3/8" x 2 7/8" | 25 | 1.55

1 5/8" x 1 7/8" | 25 | 1.50

1 5/8" x 2 3/8" | 25 | 1.55

1 5/8" x 2 7/8" | 25 | 1.10

1 5/8" x 3 1/2" | 25 | 1.89

Butterfly Latch
press to zoom
1/1

Butterfly Latch

Bolts included


Sizes: frame size x post size


Description | Per Sack | Weight Ea.

1 3/8" x 1 7/8" | 25 | 0.89

1 3/8" x 2 3/8" | 25 | 0.90

Butterfly Latch, Flatback
press to zoom
1/1

Butterfly Latch, Flatback

Lag Screws Sold Separately


Description | Per Sack | Weight Ea.

Flatback | 25 | 0.88

Kennel Clamps
press to zoom
1/1

Kennel Clamps

Approximately 1 1/8" Spacing Between Frames


Bolts Sold Separately



Description | Per Sack | Weight Ea.

1 3/8" x 1 3/8" | 100 | 0.59

Kennel Latch
press to zoom
1/1

Kennel Latch

Approximately 1 1/8" spacing between frames


Bolts Sold Separately


Description | Per Sack | Weight Ea.

1 3/8" | 50 | 1.00

Butterfly Latch, Flatback
press to zoom
1/1

Kennel Hinge

Approximately 1 1/8" spacing between frames


Bolts Sold Separately


Description | Per Sack | Weight Ea.

1 3/8" | 100 | 0.75

Drop Pin Latch + Footbolt
press to zoom
1/1

Drop Pin Latch + Footbolt

Description | Weight Ea.

Drop Pin w/ Chain | 2.00

Guides | 0.50

Foot Bolt | 3.00

Locking U | 0.00

Brace Band c/w Locking U
press to zoom
1/1

Brace Band c/w Locking U

Description

2 3/8"

2 7/8"

3 1/2"

4 1/2"

E-Z Latch
press to zoom
1/1

E-Z Latch - Residential Drop Rod

Description | Per Sack | Weight Ea.

1 3/8" x 36" Assembly | 10 | 2.17

1 3/8" x 42" Assembly | 10 | 2.31

Finger Latch Assembly
press to zoom
1/1

Finger Latch Assembly

NOTE: Bolts Included


Description | Weight Ea.

Finger - 1 3/8" | 0.75

Catch - 1 7/8" | 0.40

Catch - 2 3/8" | 0.55

Niday Spring Latch
press to zoom
1/1

Niday Spring Latch

Description | Per Sack | Weight Ea.

1 7/8" x 1 3/8" | 20 | 0.99

2 3/8" x 1 3/8" | 20 | 1.10

Flatback Hinges
press to zoom
1/1

Flatback Hinges

Lag Screws Sold Separately


Description | Per Sack | Weight Ea.

Flat Plate Pin Hinge | 100 | 0.45

Panel Clamps
press to zoom
1/1

Panel Clamps

Approximately 3/8" Spacing Between Frames


Bolts Sold Separately


Description | Per Sack | Weight Ea.

1 3/8" x 1 3/8" | 100 | 0.50

Use 3/8" x 2 1/4" Carriage Bolt

1 5/8" x 1 5/8" | 50 | 0.67

1 7/8" x 1 7/8" | 50 | 0.78

Use 3/8" x 2 1/2" Carriage Bolt

Gate Clips
press to zoom
1/1

Gate Clips

Description | Per Sack | Weight Ea.

1 3/8" | 250 | 0.13

1 5/8" | 250 | 0.16

Gate Scrolls
press to zoom
1/1

Gate Scrolls

Description | Per Sack | Weight Ea.

18" | 10 | 1.12

24" | 10 | 1.44

Drive-in Plugs
press to zoom
1/1

Drive-in Plugs

Description | Per Sack | Weight Ea.

1 3/8" | 100 | 0.08

1 5/8" | 100 | 0.10

1 7/8" | 100 | 0.13

Safe-T Line Track Brackets
press to zoom
1/1

Safe-T Line Track Brackets

Use 1 5/8" O.D. Pipe Track


Bolts Included


Description | Per Sack | Weight Ea.

1 5/8" or 1 7/8" | 20 | 2.55

2 3/8" or 2 7/8" | 20 | 2.65

3 1/2" | 20 | 2.92

Flatback Safe-T Line Track Brackets
press to zoom
1/1

Flatback Safe-T Line Track Brackets

For Flat Surface/Block Walls


Use with 1 5/8" O.D. Pipe Track


Description | Per Sack | Weight Ea.

Flat Back | 20 | 1.93

Safe-T Rear Wheel For Pipe Track
press to zoom
1/1

Safe-T Rear Wheel For Pipe Track

For 1 5/8" O.D.  Pipe Track


Bolts Included


c/w Grease Fitting


Description | Per Sack | Weight Ea.

5" Wheel | 10 | 5.75

7" Wheel* | 4 | 7.92

*c/w bracket assembly | heavy duty track wheel clamp for 1 5/8" or 1 7/8" frame

Track Wheel Clamp
press to zoom
1/1

Track Wheel Clamp

Description | Per Sack | Weight Ea.

1 5/8" or 1 7/8" | 25 | 1.75

Gate Post Collar
press to zoom
1/1

Brackets For Rear Wheel

Description | Per Sack | Weight Ea.

1 5/8" Gate Frame | 25 | 0.66

Cantilever Wheels
press to zoom
1/1

Cantilever Wheels

Bolts Included


Sizes: Post Size x Roller Size


Description | Per Sack | Weight Ea.

3 1/2" x 2 3/8" | 4 | 16.00

4 1/2" x 2 3/8" | 4 | 16.00

"Load Master II" Nylon Cantilever Wheels

Bolts Included


Sizes: Post Size x Roller Size


Description | Per Sack | Weight Ea.

3 1/2" x 2 3/8" | 4 | 11.19

4 1/2" x 2 3/8" | 4 | 11.19

Swivel Wheels
press to zoom
1/1

Swivel Wheels

Bolts Included


Description | Per Sack | Weight Ea.

1 3/8" Frame | 4 | 4.62

1 5/8" Frame | 4 | 4.71

Industrial Double-wheel Carrier
press to zoom
1/1

Industrial Double-Wheel Carrier

Bolts Included


Clamp-on Type, 5/8" Axle, 12" Wheel Base


Description | Per Sack | Weight Ea.

1 5/8" or 1 7/8" Frame, 6" Steel-Hub Wheel | 4 | 8.50

1 5/8" or 1 7/8" Frame, 8" Steel-Hub Wheel | 4 | 12.38

Pneumatic Double-wheel Carrier
press to zoom
1/1

Pneumatic Double-Wheel Carrier

Bolts Included


Clamp-on Type, 5/8" Axle, 12" Wheel Base


Pneumatic Wheels


Description | Per Sack | Weight Ea.

1 5/8" or 1 7/8" Frame, 10" Wheel | 1 | 12.34

Cantilever V-catch

Description | Part No. | Per Sack | Weight Ea.

Experience the Ease of an Automatic Driveway Gate

Do you require an automatic gate to be operated with the help of a remote? We can equip you with an automatic driveway gate for your home or facility. Duraguard Fence can assist you in deciding the right type of automatic gate for your property, in line with your needs and budget. Talk to us to discuss your particular custom gate or automatic gate needs.

Greater Level of Fit and Uniqueness

For over 30 years in the gate and fencing industry, Duraguard Fence Ltd. has been a trusted company for customized gates and easy gate installations in Alberta. Let us provide you with a tailored gate for your property that has a greater level of fit and the unique design you’ve got in your mind. We strive to offer superior craftsmanship and excellent customer service.

Wooden gate
press to zoom
Wooden entry gate
press to zoom
Iron gate
press to zoom
Iron gate
press to zoom
Iron gate
press to zoom
1/1
call icon

Custom Gates Inquiry

Get more information on our custom gates, electromechanical and hydraulic operators.
