ACCESSORIES FOR ORNAMENTAL IRON FENCES
Duraguard Fence Ltd. is a trusted manufacturer and supplier of fencing products in Edmonton and throughout Alberta. We strive to provide you with quality fencing products, suitable for a variety of applications. Our sales and services team is always ready to discuss your exact requirements for custom-made fences. Please browse our catalogue of tools and contact us for more information or to request a quote.
2" Square Post - 16 Gauge
Pyramid Cap Included
Description | Qty | Weight Ea.
5'9" | 88 | 9.20
6'9" | 88 | 10.80
7'9" | 88 | 12.30
8'9 | 88 | 14.00
2 1/2" Square Post - 16 Gauge
Pyramid Cap Included
Description | Qty | Weight Ea.
7' | 48 | 15.00
8' | 48 | 17.00
9' | 48 | 20.00
11' (11 Gauge) | 48 | 24.00
3" Square Post - 12 Gauge
Description | Qty | Weight Ea.
10' | 1 | 36.00
4" Square Post - 11 Gauge
Description | Qty
8' | 1
10' | 1
6" Square Post x .1875" Wall
Description | Qty
10' | 1
NOTE:
When installed in locations subject to freezing temperatures, where posts are grouted into core-drilled holes, a .25" hole must be drilled into the post approximately .5" above the elevation. This allows for proper drainage of groundwater build-up. The drilled hole must be clean & dry prior to applying zinc primer & colour finish. Failure to follow these practices voids the warranty of the fence system.
3/4" Square 18 ga. Pickets (19 per panel - 4" Air-Space)
1 7/16" x 1 1/2" x 91 15/16" L 14ga. Punched steel channel (3 per panel)
Description | Per Lift | Weight Ea.
4' Nominal Height (46" Net) | 40 | 60.00
5' Nominal Height (58" Net) | 40 | 69.00
6' Nominal Height (70" Net) | 40 | 78.00
Square Post Pyramid Caps
Description | Qty | Weight Ea.
2" Pressed Steel | 1 | 0.14
2 1/2" Pressed Steel | 1 | 0.22
Square Post Ball Caps
Description | Qty | Weight Ea.
2" Pressed Steel | 1 | 0.60
Panel Mounting Brackets
Description | Qty | Weight Ea.
2" Universal Bracket | 1 | 0.54
Comes with #10 x 3/4" self-drilling screws | 1/4" x 1 1/2" carriage bolts | 1/4" flange nuts
2" Line Bracket | 1 | 0.64
Comes with #10 x 3/4" self-drilling screws | 1/4" x 1 1/2" carriage bolts | 1/4" flange nuts
Use as a Boulevard bracket around a 2" post to join two adjacent fence panels in-line
Montage Flat Back | 1 | 0.9
Comes with #14 x 3/4" self-drilling screws | 1/4" x 1 1/2" carriage bolts | 1/4" flange nuts
Use to attach fence panels to walls, wood posts, etc.
Montage Swivel | 1 | 0.54
Comes with #10 x 3/4" self-drilling screws
Use for oblique angle intersections
Panel Mounting Brackets - Montage Plus
Description | Qty | Weight Ea.
2 1/2" Universal | 1 | 0.45
Comes with #10 x 3/4" self-drilling screws | 1/4" x 1 1/2" carriage bolts | 1/4" flange nuts
2 1/2" Line | 1 | 0.64
Comes with #10 x 3/4" self-drilling screws | 1/4" x 1 1/2" carriage bolts | 1/4" flange nuts
Use as a Boulevard bracket around a 2" post to join two adjacent fence panels in-line
Montage Plus Flat Back | 1 | 0.27
Comes with #14 x 3/4" self-drilling screws | 1/4" x 1 1/2" carriage bolts | 1/4" flange nuts
Use to attach fence panels to walls, wood posts, etc.
Montage Plus Swivel | 1 | 0.2
Comes with #10 x 3/4" self-drilling screws
Finials
Cast Aluminum - Polyester Powder Coated
Description | Qty | Weight Ea.
5/8" Quad Flair | 1 | 0.12
5/8" Triad | 0.14
3/4" Quad Flair | 0.15
Rings
Cast Aluminum - Polyester Powder Coated
#10 Self-Drilling Screws Included
Description | Qty | Weight Ea.
Corona Ring | 1 | 0.45
Fits on face of 5/8" Pickets - 11 Per Panel
4" Double Ring - Montage Plus | 1 | 0.70
Fits on face of 3/4" Pickets - 10 Per Panel
Montage Welded Single Pedestrian Gate Kit
Gate Ends + Hardware
2 x Gate Ends - 1.25" sq. | 1 x Fork Latch - 2" | 1 Latch Collar - 1.25"
2 x Post Hinges - Male - 2" Square | 2 x Frame Hinges - Female - 1.25" sq.
Description | Qty | Weight Ea.
4' High | 1 | 14.00
5' High | 1 | 16.00
6' High | 1 | 18.00
Montage Plus Gate Hardware
Gate Hardware Included
1 3/4" Square 14 ga. Gate Ends | 3/4" Square 18 ga. Pickets
Fits 48" Opening I/I - Custom Sizes Extra
Description
4' High
5' High
6' High
Montage Plus Gate Ends
1 3/4" Square 14 ga. Gate Ends
Description | Qty | Weight Ea.
4' High Ends | 1 | 6.90
5' High Ends | 1 | 8.75
6' High Ends | 1 | 10.50
Post Hinge
Bolts Included
Description | Qty | Weight Ea.
2" Square |1 | 0.65
2 1/2" Square | 1 | 0.69
Frame Hinge
Bolts Included
Description | Qty | Weight Ea.
1 1/4" Square Frame | 1 | 0.55
1 3/4" Square Frame | 1 | 0.60
2 " Square Frame | 1 | 0.68
Plate Pintle
Description | Qty | Weight Ea.
5/8" Pin | 1 | 0.44
Fork Latch
Description | Qty | Weight Ea.
1 1/4" Square | 1 | 0.34
1 3/4" Square | 1 | 0.40
2" Square | 1 | 0.40
2 1/2" Square | 1 | 0.60
3" Square | 1 | 0.61
Fork Latch Collar
Description | Qty | Weight Ea.
1 1/4" Square | 1 | 0.52
1 3/4" Square | 1 | 0.60
2" Square | 1 | 0.60
Flat Back Fork Latch Plate
Description | Qty | Weight Ea.
Flat Back | 1 | 0.32
Post Base Plate
Description | Qty | Weight Ea.
Fits 2" Square Post | 1 | 2.20
Cane Bolt
Note: Use with Two Frame Hinges (Sold Separately)
A459
Description | Qty | Weight Ea.
5/8" x 48" | 1 | 4.00
Estate Gate Hardware
Description | Per Lift
4" Adjustable Hardware | 1
Heavy Duty Centre Latch | 1
6" Adjustable Hardware | 1
